SPECIFICATIONS

Dimension

Φ:1.5~mm, L:0.5~30mm(Customized available)

Diameter

Tolerance

+0/-0.1mm

Thickness Tolerance

±0.1mm

Chamfer

0.2mmX45°

Parallelism

＜1′

Flatness

≤λ/4@632.8nm

Barrel

Finish  ground

Incidence

Angle

0° or 45°±5°

Coating

Upon  customer’s  request

Surface

Quality

40/20(MIL-PRF-13830B)

TIPICAL   PRODUCTS

Diameter

(mm)

Thickness

(mm)

Curvature

(mm)

Incidence

Angle

Wavelength

(nm)

12.7

3/4/5

∞

0°

1064/808

15/20

3/5

∞

0°or 45°

1064/808/532/355

20

5

-2000/-3000/

-4000/-6000

0°

1064/808/532/355

25.4

3/4/5

∞

0°or 45°

1064/808/532/355

30/35/40/45

5

∞

45°

1064/808/532/355
