SPECIFICATIONS | |
Output Wavelength | 585nm |
Input Wavelength | 532nm |
Size | φ31.5×178mm |
Conversion efficiency | 65-70% |
Beam Size | Input 12-15mm, Output 2-3mm |
Life Time | >20k pulses |
Threaded Interface | M22×1.5, Length:8mm |
| NOTE | |
Input must be pure 532nm laser; Flat top beam is preferred; Repetition Rate of 1-2Hz is recommended for extended life time Power density should be 0.5J/cm2 532nm,8~10ns |
