SPECIFICATIONS

Dimension

Diameter:1~50mm,Length:0.3~220mm(Customized  available)

Dimension Tolerance

Φ:+0/-0.04mm,L:+0.5/-0mm

Perpendicularity

≤5′

Parallelism

≤10″

Chamfer

0.15±0.05mm

Clear Aperture

＞95%

Surface Quality

10/5(MIL-PRF-13830B)

Barrel

Fine Ground, Polishing, Grooving

Flatness

≤λ/10@632.8nm

Wavefront Distortion

≤λ/10 per inch@632.8nm

Extinction Ratio

≥30dB

Coating

AR coating:R<0.15%@1064nm,R<0.5%@808nm,R<0.15%@532nm

PR coating:R=(10~90)%±2%@1064nm

HR  coating:R>99.8%@1064nm,R>99.8%@808nm

Damage Threshold

≥1GW/cm²@1064nm,10ns,10Hz

MATERIAL

CONCENTRATION

APERTURE (MM)

LENGTH (MM)

Nd:YAG+Cr⁴⁺:YAG

Nd:0.1at%~3.0at%,Cr:0.6~8.5/cm

2×2~20×20

0.5~200

YAG+Nd:YAG

0.1at%~3.0at%

2×2~20×20

0.5~200

YAG+Nd:YAG+YAG

0.1at%~3.0at%

2×2~20×20

0.5~200

YAG+Nd:YAG+Cr⁴⁺:YAG

Nd:0.1at%~3.0at%,Cr:0.6~8.5/cm

2×2~20×20

0.5~200

YVO₄+Nd:YVO₄

0.1at%~3.0at%

2×2~20×20

0.5~200

YVO₄+Nd:YVO₄+YVO₄

0.1at%~3.0at%

2×2~20×20

0.5~200

YVO₄+Nd:YVO₄+YVO₄

0.1at%~3.0at%

Φ2~15

0.5~200

Glass+Er,Yb:glass+Co:spinel

Co:0.12at%~0.85at%

1×1~3×3

8~10
